Basic characteristics
Combined with the wear resistance of copper alloy and solid self-lubricating properties of the lubricant to use in the process of maintaining without refueling. Products are widely used in high-contained, intermittent or swing movement, such as steam locomotive production lines, turbine and reservoirs work / accident doors, plastic machinery. According to the conditions, can provide various types of copper alloy.



Unit : mm
Stanard No W L T I a b
JZP-75*130 75 130 30 95 40 50
JZP-75*150 150 45 90 45
JZP-75*170 170 60
JZP-75*200 200 120 75
JZP-100*130 100 130 30 95 60 50
JZP-100*150 150 45 90 45
JZP-100*170 170 60
JZP-100*200 200 120 75
JZP-125*130 125 130 30 95 85 50
JZP-125*150 150 45 90 45
JZP-125*170 170 60
JZP-125*200 200 120 75
JZP-150*130 150 130 30 95 110 50
JZP-150*150 150 45 90 45
JZP-150*170 170 60
JZP-150*200 200 120 75
