ㆍServices |
| |
Cooling sea water pump |
| |
Cooling fresh water pump |
| |
Central cooling fresh water pump |
| |
Ballast pump |
| |
Inert gas cooling sea water pump |
| |
Turbo generator condenser cooling pump |
| |
Others |
|
 |
| Dimensions (SVA from 200 to 400) |
|
 |
| |
| Item / Model |
SVA 2100 |
SVA 250 |
SVA 300(A) |
SVA 350(A) |
SVA 350(A) |
| Rotation |
Clockwise when viewed from driver end |
| Suction bore (mm) |
200 |
250 |
300 |
350 |
400 |
| Discharge bore (mm) |
200 |
250 |
300 |
350 |
400 |
| Stuffing box seal |
Gland packing or Mechanical seal |
| Weight : Cast Iron (Bronze) (kg) |
310(360) |
400(460) |
510(570) |
675(730) |
1050(1160) |
| Water filled in casing (kg) |
51 |
90 |
125 |
195 |
315 |
|
|
 |
 |
 |
| |
| SVA from 200 to 400 |
 |
| mm |
| Model |
A |
B |
C |
E |
F1 |
F2 |
F3 |
H |
H1 |
H2 |
I |
K |
M |
M1 |
M2 |
N |
N1 |
N2 |
X |
Z |
Mecha.seal |
| SVA 200 |
255 |
255 |
400 |
400 |
305 |
315 |
550 |
810 |
914 |
849 |
90 |
500 |
145 |
205 |
145 |
170 |
230 |
170 |
200 |
27 |
45 |
| SVA 250(A) |
290 |
290 |
430 |
430 |
305 |
350 |
550 |
881 |
958 |
920 |
90 |
500 |
180 |
240 |
180 |
210 |
270 |
210 |
200 |
27 |
55 |
| SVA 300(A) |
325 |
325 |
470 |
470 |
310 |
390 |
555 |
941 |
1040 |
980 |
110 |
500 |
200 |
275 |
200 |
230 |
305 |
230 |
200 |
33 |
55 |
| SVA 350(A) |
355 |
355 |
480 |
480 |
365 |
380 |
600 |
1031 |
1115 |
1050 |
110 |
540 |
235 |
300 |
235 |
265 |
330 |
265 |
230 |
33 |
60 |
| SVA 400(A) |
410 |
410 |
600 |
580 |
430 |
495 |
600 |
1171 |
1255 |
1190 |
110 |
540 |
275 |
355 |
275 |
305 |
385 |
305 |
230 |
33 |
70 |
|
|
|
 |
| |
| Discharge pressure gauge |
1 |
| Suction compound gauge |
1 |
| Gauge board |
1 |
| Gauge root valve |
2 |
| Sealing pipe |
1 set |
| Air vent valve |
1 |
| Vacuum pump(for self priming pump) |
1 set |
|
|
 |
| |
| 1 pump set of the following spare parts is supplied for 1 ship |
| Gland packing or mechanical seal |
| Coupling bolt & nut |
| Mouth ring |
| Line bearing |
| Complete set of rotating element(if required) |
|
|
| |
