FIRE & G/S PUMP
EMERGENCY FIRE PUMP



The stuffing box is fitted with gland packing, but a mechanical seal can be fitted
if the customer requires it to eliminate gland adjustment


Capacity : 30 m©ø/Hr ~ 540 m©ø/Hr
Head : 40 m ~ 160 m
Suction Dimension : ©ª100 mm ~ ©ª250 mm
Rotation Direction : CW
The out of the above range can be supplied according to customer's order placement
