HOT WATER CIRC. PUMP
M/E JACKET.C.F.W. PUMP
FRESH. WATER PUMP


Back-full-out feature for easy maintenance
Great variety in metallic materials for corrosion and wear resistance
Good efficiency smooth and trouble free operation throughout a wide range of hydraulic coverage
Un-cooled stuffing box, Packing ring or mechanical seal


Capacity : 0.05 m©ø/min ~ 35 m©ø/min
Head : 3 m ~ 92 m
Suction Dimension : ©ª40 mm ~ ©ª400 mm
Rotation Direction : CW
The out of the above range can be supplied according to customer's order placement
